Sneaky tricks for developing on small devices – Bitmap ‘folding’

One of the most problematic constraints when developing applications for mobile or Set Top Box is video memory. You often will not have control over how much video memory is allocated to your application, or what the fallback behaviour is when your application uses too much.

This can be a pain, especially when you wish to create some off-screen surfaces for caching or compositing to improve performance.

If your application runs too slowly, that’s a problem; if your application crashes due to excessive memory usage, that’s a REAL problem.

I recently built a feature into an application which required a bunch of external images to be loaded into a Set Top Box device for in-process caching. Since all Bitmap surfaces are allocated on the platform as ARGB, but the images were monochrome, I could store the images efficiently AND make them available for hardware-accelerated compositing by storing just the single monochrome channel of each image in a separate channel of an in-process cache Bitmap surface.

You can see in the attached image what a a mish-mash of logos is created. For debugging purposes, you can also see the same surface viewed with each other channel turned off. When a logo is requested, a dictionary finds the relevant Bitmap slot it exists in (given by a Rectangle and BitmapDataChannel number). When a new image is loaded, its single channel is copied into the next available slot in the cache, in FIFO fashion.

The alpha channel of the cache surface wasn’t used, due to the pre-multiplication problems you’ll get. The result is an in-process cache requiring no image decoding to composite images, storing 3 times as many images as a regular Bitmap FIFO. #WIN

O’Donnell’s 3 Laws of User Dynamics

Remember kids: You don’t have to please ALL your customers, just the ones you want to keep.

sheepThe first Law: conservation of users

Users are not created or destroyed, only converted to or from using a competitor’s product.

All other things being equal, you should remember that brand loyalty counts for less and less these days. If you don’t want to do what your users are asking for, maybe your competitors will.

polar bearsThe second law: the progress of disorder

Evolve your product, in order to fight ‘design entropy’.

As users’ needs change, so should your product. If you don’t have the right metrics in place, you won’t realise that your product is obsolete until you become the next Woolworths.

designThe third law: chasing perfection

Invent something idiot-proof and someone will invent a better idiot.

Humans are complex and often unpredictable. Therefore, human-computer interfaces are, at best, imperfect systems. Test your design assumptions and always have documented justification for design decisions that can be re-tested against new iterations of your product.

Wait for it…

Improving the usability of an interface, by making it do more or less what the user actually expects of it, is a pretty good route to an overall sound user experience. Yet, there’s one key mistake almost every interface I’ve looked at makes in this regard – what I call the Spurious Stimulus Response. That is…

responding to user input in the context of stimuli they haven’t been given the time to acknowledge.

For example, consider a dialog box, suddenly appearing centre-stage in an interface, as the result of an incoming message, error condition, or some such situation. If the user was to click on it, or press a key, within 250 milliseconds of it appearing, then they are not reacting to its appearance – instead they were probably intending to action something else.

In an interface without a pointing device, such as on TV, using a traditional remote control, the problem is exacerbated, since the user only need press OK to commit whatever action happens to come into focus. When using an infra-red remote control, this problem is compounded further, because it usually takes a fraction of a second for the receiving device to recognise the incoming IR pulses as something it needs to deal with and push that signal up through the software stack to the UI layer.

I suggest employing a simple fix, which draws its inspiration from the behaviour of nerve stimulation – called the refractory period. That is…

to render a control inactionable, after a change in UI state, long enough for the user to assimilate said state change.

The few interfaces which loosely employ some such technique, do so usually just as a side-effect of having some animated transition when a dialog appears, for example. Sometimes, a button or other control is disabled until the transition completes. This is actually a very good way of ‘easing the user into’ the change in UI state – but a refractory period should still be implemented where animation is absent.

The refractory period could be some function of the amount/importance of information provided. A good example of this is the Firefox Add-on confirmation dialog, which forces you to wait a few seconds, rather than letting you mash RETURN and install some random plugin.

But, in its most simple incarnation, a refractory period may simply be used to filter out double-click mania. Please start designing this kind of behaviour into your UIs – your users will thank you.

Chinese Handwriting Recognition App

Unlike the iPad, the BlackBerry PlayBook has rather poor international keyboard support, with no method for entering chinese characters. I like the way iOS achieves this, so went about building my own version in ActionScript.

This was mainly an academic exercise and to help me to learn to write chinese. My approach was to sample the strokes drawn into the app as a series of up to 8 directions, including the relative position of a given stroke to the previous stroke, again as one of 8 directions. This pattern, represented as a string of numbers is then put through a smoothing algorithm, to remove some unnecessary noise and then compared with a dictionary of pattern keys, which may contain one or more suggested characters. If there are no hits, an advanced search occurs, by mutating the given pattern in specific ways, in order to find alternative suggestions. I can also find characters based on the next most likely character to the one you’ve just entered, using frequency analysis on given sample text.

The app will eventually be a PlayBook App, but is still unfinished and currently in ‘training mode’, so that character patterns can be trained into the database. It’s currently primed with some simplified sample data, from which it picks the most popular few characters to learn. If you write chinese, give it a go.

SmoothBitmap – How to enforce pixel smoothing on a Bitmap

A common oversight when using Bitmaps with loaded content is that Flash will revert a Bitmap’s smoothing parameter to false when you replace its bitmapData. It’s simple enough to fix, but since you may not know if someone is going to replace the bitmapData of a Bitmap you have created – then it’s often better to code defensively around it.

This little SmoothBitmap class is for just such an occassion. Instantiate it like a regular Bitmap and, no matter what another developer does with it, smooth pixels when scaling/rotating will be ensured.

CODING WRONGS – Where do I start with the bad?

It gets scary out there sometimes. During my freelance career I’ve worked at a lot of different companies and have seen such coding horrors as you cannot imagine. So I thought I’d start immortalising some of them – so that we can all learn better coding practices, by looking at the bad.

Starter for 10 – What’s wrong with this picture?

Did you spot the fubar? It’s not an obvious one.

This code potentially replaces a Bitmap’s BitmapData, without first explicitly disposing any existing BitmapData.

I see this kind of thing quite often and it’s the source of many a memory leak. AVM2 isn’t that great at dealing with this kind of situation and there’s a crucial difference between GC cleaning up out-of-scope objects for you and things like BitmapData: GC will reclaim the memory associated with objects ‘when it feels like it’, whereas explicitly calling the ‘dispose’ method of a BitmapData will immediately give you back that memory.

In the case of platforms with hardware accelerated graphics (such as mobile or set top box), the memory associated with the pixel data itself (video memory) will be reclaimed immediately.

The lesson?

Don’t make more work for the Garbage Collector when you can avoid it.

TextField.getRawText() what it does

I was recently creating an API that required extending TextField and happened across the getRawText() method. I assumed this returned the text from the field without formatting or something – so I looked up the AS3 docs for flash.text.TextField.

Nothing there – gee thanks Adobe. A quick search turned up this which, it turns out, isn’t quite accurate.

So, with a tad of testing, it appears that getRawText() returns the text, stripped of any HTML tags (if you had set htmlText). I now wonder if this is faster than using a RegEx to strip the tags and why Adobe didn’t document it?
